IEC Power Cord Types Explained

In the world of electronics, one component that often goes unnoticed but is absolutely essential is the IEC power cord. Whether you're setting up a home computer, installing networking equipment, or connecting data center servers, the right power cord ensures safe, stable, and compatible electricity flow. With various IEC power cord types available, understanding the differences between them is crucial for choosing the right one for your devices.


What Is an IEC Power Cord?

IEC power cords are cables that comply with the standards set by the International Electrotechnical Commission (IEC), particularly the IEC 60320 specification. These cords are widely used across IT equipment, household appliances, and industrial machines. The designation “IEC” ensures international compatibility and safety, making them a trusted standard globally.

IEC power cords consist of two key elements:

  • Plug (Connector) Type: Connects to your equipment.

  • Receptacle (Socket) Type: Connects to the power source, often via country-specific plugs.

The IEC 60320 standard classifies connectors based on their current and temperature ratings. Each type is assigned a letter-number code, such as C13, C14, C19, and so on.


Common IEC Power Cord Types

Here are the most commonly used IEC power cord types and their applications:

  1. IEC C13 to C14

IEC C13 to C14IEC C13 to C14IEC C13 to C14

  • Rating: 10A, 250V

  • Temperature Rating: Up to 70°C

  • Application: Desktop computers, monitors, printers, and networking equipment

The C13 (female) connector plugs into equipment, while the C14 (male) end plugs into a PDU (Power Distribution Unit) or power source. This is arguably the most commonly used IEC power cord type in offices and data centers.


2. IEC C19 to C20

IEC C19 to C20IEC C19 to C20

  • Rating: 16A, 250V

  • Temperature Rating: Up to 70°C

  • Application: High-power servers, UPS systems, large network switches

This type is similar in design to C13/C14 but supports higher current. The C19 (female) connector goes to the equipment, while the C20 (male) plugs into a power source.


3. IEC C5 to C6 (Cloverleaf)

IEC C5 to C6IEC C5 to C6IEC C5 to C6

  • Rating: 2.5A, 250V

  • Temperature Rating: Up to 70°C

  • Application: Laptop power supplies, projectors, portable electronics

The C5 is also called a "Mickey Mouse" or "Cloverleaf" connector due to its shape. The C6 end connects to the power source.


4. IEC C7 to C8 (Figure-8)

IEC C7 to C8IEC C7 to C8IEC C7 to C8

  • Rating: 2.5A, 250V

  • Temperature Rating: Up to 70°C

  • Application: Small appliances, DVD players, game consoles

The C7 connector is recognizable by its rounded, figure-8 shape. It’s a non-polarized plug, and the C8 is its male counterpart.


5. IEC C15 to C16

IEC C15 to C16IEC C15 to C16

  • Rating: 10A, 250V

  • Temperature Rating: Up to 120°C

  • Application: Electric kettles, high-temperature devices

C15/C16 connectors are similar to C13/C14 but can withstand higher heat, making them ideal for equipment that generates more thermal output.


Regional Variants and Plug Adapters

While IEC connectors maintain a standard globally, the plug that connects to the wall socket varies by region. For instance:

  • NEMA 5-15P to C13 is common in North America.

  • CEE 7/7 (Schuko) to C13 is used in Europe.

  • UK BS1363 to C13 is used in the UK.

You can also find universal power cords or adapters that support multiple plug types, ideal for international travel or global business equipment compatibility.


Choosing the Right IEC Power Cord

Here are some tips to choose the best IEC power cord type for your application:

  1. Check Device Requirements: Look at the current and voltage specifications.

  2. Consider Temperature Range: Choose C15/C16 if your equipment operates at higher temperatures.

  3. Check the Connector Shape: Match the cord to the equipment’s inlet—C13/C14, C19/C20, etc.

  4. Think About Cable Length: Don’t use excessively long cords if not needed—it can affect power efficiency.

  5. Use Certified Cords: Ensure compliance with international safety certifications like UL, CE, or RoHS.

  6. Check Country Compatibility: Always ensure the cord has the correct wall plug type for your region (e.g., NEMA for the US, Schuko for EU, BS1363 for the UK) or use a reliable adapter if necessary.


Where Are IEC Power Cords Used?

IEC power cords are prevalent in many industries:

  • IT and Data Centers: Servers, switches, routers

  • Home Electronics: TVs, game consoles, computers

  • Office Equipment: Printers, projectors

  • Industrial Systems: High-current power systems

  • Hospital Equipment: Medical-grade IEC cords are used for added safety

Their versatility and safety make them a global standard for reliable power connections.


Conclusion

Choosing the correct IEC power cord type is essential for safe and efficient operation of your electrical equipment. By understanding the differences in connector shapes, ratings, and applications, you can ensure that your setup meets power demands without risk of overheating or electrical failure.

Whether you're building a data center or replacing a laptop power cable, knowing your IEC C13 from C19 can save time, money, and prevent downtime. Always opt for high-quality, certified cords tailored to your device’s requirements.

For high-quality and globally compatible IEC power cords, Aline offers a wide range of certified options to meet your specific needs.
